Padel Court — Model Club
A complete padel court system built around a hot-dip galvanised MS steel structure, 12 mm tempered float glass and 12 mm curly mono-filament turf. Every component — from the welded mesh frame to the jam-free tensioning posts — is specified for professional standards of play and long service life in both indoor and outdoor installations.
Built for performance. Designed to last.
Model Club is our standard padel court specification — the configuration most clubs install. It pairs a galvanised, sand-blasted and powder-coated steel structure with tempered glass and cushioned rubber isolation, so the court plays true and holds its finish season after season, indoors or out.
Why choose our Padel Court — Model Club?
Durability
Engineered for strength and long-term use.
Performance
Designed to meet professional standards for play.
Outdoor & Indoor Use
Built to perform in every environment.
Corrosion Resistant
Hot-dip galvanised steel with stainless steel fasteners.
Player Safety
Tempered glass with cushioned rubber shock absorption.
1.Structure
Main frame constructed using MS steel posts of size 100 x 50 x 3 mm & 80 x 40 x 2 mm, with base plate.
Mesh frame made from 40 x 40 x 2 mm MS pipes.
Welded mesh size 50 x 50 x 4 mm.
Angled lighting posts of size 80 x 40 x 2 mm.
Designed for durability, rigidity, and long-term indoor and outdoor performance.
2.Glass Panels
- 12 mm thick tempered float glass with polished edges and countersunk drilled holes.
- Ensures high impact resistance and player safety.
3.Glass Protection Rubber
- Cellular chloroprene rubber or EPDM rubber (40 mm x 2 mm).
- Installed between glass and metal structure.
- Provides shock absorption, vibration reduction, and protection.
4.Artificial Turf — Floor
- Composition: PE (Polyethylene)
- Structure: Curly mono-filament turf
- DTEX: 9,000 ±10%
- Pile height: 12 mm ±1 mm
- Gauge: 3/16"
- Stitch /10 cm (ISO 1763): 22±3%
- Backing cloth: PP + NET
- Coating: Latex
- Stabilizing infill: Quartz sand
- Colour: Blue
5.Padel Post
- Post made of 80 x 3 mm square tube including post caps.
- Manual winch, jam-free cable tensioning hardware system.
- Can be provided with base plate for fasteners, and net.
- Side & bottom headline cable.
- With loop & pin finish etc.
